ZTE F663NV3A ONU With 2GE 2FE 2.4G WIFI English Firmware GPON ONT

Shenzhen UT-King Technology Co., Ltd.
Contact Now
    Buy cheap ZTE F663NV3A ONU With 2GE 2FE 2.4G WIFI English Firmware GPON ONT from wholesalers

    Buy cheap ZTE F663NV3A ONU With 2GE 2FE 2.4G WIFI English Firmware GPON ONT from wholesalers
    • Buy cheap ZTE F663NV3A ONU With 2GE 2FE 2.4G WIFI English Firmware GPON ONT from wholesalers
    • Buy cheap ZTE F663NV3A ONU With 2GE 2FE 2.4G WIFI English Firmware GPON ONT from wholesalers
    • Buy cheap ZTE F663NV3A ONU With 2GE 2FE 2.4G WIFI English Firmware GPON ONT from wholesalers
    • Buy cheap ZTE F663NV3A ONU With 2GE 2FE 2.4G WIFI English Firmware GPON ONT from wholesalers

    ZTE F663NV3A ONU With 2GE 2FE 2.4G WIFI English Firmware GPON ONT

    Ask Lasest Price
    Brand Name : ZTE
    Model Number : F663NV3A
    Price : USD 13-17 per pieces
    Payment Terms : T/T, Western Union
    Supply Ability : 1000pcs one week
    Delivery Time : 5-12 work days
    • Product Details
    • Company Profile

    ZTE F663NV3A ONU With 2GE 2FE 2.4G WIFI English Firmware GPON ONT

    ZTE F663NV3A ONU with 2GE 2FE 2.4G WIFI English Firmware GPON ONT

    Product Features
    ZTE ZXHN F663NV3a FTTH is a single-frequency and economical smart gateway specially built by ZTE for China Mobile. This model uses the new-generation self-developed chip, loads the intelligent operating system, and supports dynamic loading of plug-ins, and givess users with abundant home services. The stable wireless performance provides smooth Wi-Fi for the home. Its unique open application platform creates an operator-dominated and user-centered smart home application ecosystem.

    Product Feature:
    * highly reliable heat dissipation design guarantees its stable operation.
    * dual image ensures uninterrupted services during software downloading or upgrading, thereby enhancing software reliability
    * highly reliable lightning protection design provides lightning and surge protection of 4 kV for the adapter, 1.5 kV for the
    Phone interfaces, and 1.5 kV for the Ethernet ports.
    * full-service access capability featuring high bandwidth, high performance, high reliability, and easy operation, administration and maintenance (OMCI/TR-069) meets the continuously changing requirements of the customer, protects the legacy investment, and enhances the value of the operator’s network.
    Product Paramenters
    Technical items
    Descriptions
    Brand
    ZTE
    Model
    ZXHN F663NV3a
    Fiber interface
    SC/UPC
    Fiber port
    1 GPON interface, 2GE+2FE LAN port + 2.4G WIFI, SC single-mode,
    Downstream rate 2.5Gbps, Upstream rate 1.25Gbps
    Wavelength
    Tx 1310nm, Rx 1490nm
    Voice protocol
    SIP, H.248
    RX sensitivity
    <-27dBm (1490nm)
    WLAN
    IEEE802.11b/g/n,2*2 MIMO, 2.4G WIFI,external antenna
    Net weight
    ≤0.6Kg
    Configuration method
    NMS, Web, or TR069
    Power
    ≤8W
    DC power
    Adapter input: 100-240 V AC, 50 – 60 Hz ;
    Adapter output: 11 – 14 V DC, 1 A
    Button
    Reset, power
    Operation
    Working temperature: -0-+40℃
    working humidity:5-95%(non-condensation)
    Dimension
    250*220*65mm(length*width*height)
    L2 forwarding capability
    Forwarding packets of any length at wire speed
    IPv4 L3 forwarding capability
    2Gbit/s with any length packets in downstream direction
    1Gbit/s with any length packets in upstream direction
    IPv6 L3 forwarding capability
    2Gbit/s with any length packets in downstream direction
    1Gbit/s with any length packets in upstream direction
    LAN
    1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface
    Details Images

    ZTE F663NV3A ONU With 2GE 2FE 2.4G WIFI English Firmware GPON ONTZTE F663NV3A ONU With 2GE 2FE 2.4G WIFI English Firmware GPON ONTZTE F663NV3A ONU With 2GE 2FE 2.4G WIFI English Firmware GPON ONTZTE F663NV3A ONU With 2GE 2FE 2.4G WIFI English Firmware GPON ONT
